Flatbed curtain side trailers can offer cargo the protection of a van and the loading flexibility of a flatbed. The benefits that this type of trailer has to offer are numerous.
Customers will enjoy a peace of mind by knowing that 40 foot curtain side trailer can protect their cargo as it would been a van or a box trailer, whereas truck drivers will enjoy the easy and quick loading and unloading from the sides and back of the trailer.
Curtain side trailer for sale near me can simply handle whatever cargo challenges your daily schedule throws your way.
40 Foot Curtain Side Trailer | Flatbed Curtain Side Trailers for Sale Near Me
40 Foot Curtain Side Trailer | Flatbed Curtain Side Trailers for Sale Near Me
40 Foot Curtain Side Trailer | Flatbed Curtain Side Trailers for Sale Near Me
Overall dimension: 12500x2500x4380mm
Payload: 60, 000kg
Side: made of reinforced PVC curtains
Axles: 3 axles, 13T/16T ,FUWA/ BPW/ TITAN Brand
Tire: 12 units, 12.00R22.5 or 315/80R22.5
Rim: 9.00-22.5 or 9.75-22.5
Suspension: Mechanical suspension(Germany or America type)
Spring Leaf: 90(W)mmx13(Thickness)mmx10 layers
King Pin: JOST brand 2.0 or 3.5 inch (bolted or welded)
Landing Gear: JOST brand D200T or Chinese brand 28tons(double-speed)
Main Beam: Height: 500mm, Upper plate:14mm, Middle plate:8mm, Bottom plate:16mm, Material:Q345B steel
Platform: 3mm-thick checkered plate
Brake Chamber: WABCO RE 6 relay valve; T30/30+T30 spring brake chamber(TKL brand), 45L air tank
Valve: WABCO valve (specially intended for oversea market)
ABS: Optional
Light: LED light (specially intended for oversea market)
Voltage: 24V
Socket(Receptacle): 7-pin Socket (for 7 wire harness)
Tool Box: 1m x 0.5m x 0.5m (The tool box contains 1 tire spanner, 1 gudgeon sleeve and 1 cranking bar. Its size can be tailored to suit your needs)
Painting: Sandblasted, anti-rust chassis surface is available with 1 layer of anticorrosive primer and 2 layers of top coats
